• Powerful brushless motor
  • Reactive Force Control (RFC)
  • Easy and stable to operate
  • High performance hammering mechanism
  • Pistol-grip handle for ease of use
  • Lightweight


Capacity Drill bit (Max. dia.) Concrete  3.4 to 26 mm (1/8” to 1-1/32”)
Steel  13 mm (1/2”)
Wood  27 mm (1-1/16”)
Core bit (Max. dia.)  50 mm (2”)
Usable drill bits SDS-plus
No-load rotation speed 0 to 950 min-¹
Full-load impact rate 0 to 4,300 min-¹
LED light  White LED
Type of motor Brushless
Type of power 18V
Type of switch DC-speed control switch (with variable speed control and brake)
Type of handle  Pistol-grip handle and side handle
Weight 2.8kg (without battery)
Dimensions (L x H x W) 368 x 276 x 83 mm
