Description

  • Powerful brushless motor
  • High speed performance
  • Compact and lightweight
  • 2 speed mode (Low/High)
  • Easy access clutch dial
  • Spindle lock function
  • LED light

Specifications

Type of power  18V
Type of motor  Brushless
Capacity Driving screw Machine  6mm
Wood 8mm dia x 100mm (with prepared holes)
Drilling 1.6mm Steel  13mm
1.6mm Aluminium  13mm
18mm Wood 50mm
Drill chuck capacity Mount type  Screw on (UNF 1/2" to 20)
Diameter  1.5-13mm
No load speed Low  0-400 (min-¹)
High  0-1,800 (min-¹)
Max. impact rate Low 6000 (min-¹)
High 27,000  (min-¹)
Max. torque Soft  40Nm
Hard  70Nm
Slip torque  22 positions 1.0-4.5Nm
Weight  1.7kg
Dimensions (L x W x H )  184 x 233 x 78mm
