Description
- Powerful brushless motor
- High speed performance
- Compact and lightweight
- Variable speed trigger switch
- Forward/reverse changeover lever with brake
- LED light
Specifications
Type of power | 18V | |
Type of motor | Brushless | |
Capacity | Small screw | 4-8mm |
Standard bolt | M5-M16 | |
High strength bolt | M5-M12 | |
Tightening torque*¹ | 172Nm | |
Tip condition | 6.35mm bit holder | |
No load speed | 0-3,100 (min-¹) | |
Impact rate | 0-3,400 (min-¹) | |
Max. tightening torque | 172Nm | |
Weight | 1.3kg | |
Dimensions (L x H ) | 128 x 222 mm | |
*¹: This torque is measured when tightening an M16 high strength bolt (strength rating 12.9) for 3 seconds with a hexagonal socket. |
