Description
- Twin belt drive for low noise and smooth cutting
- Motor head slides on fixed pipe to optimise use in narrow spaces
- Laser guide system for improved accuracy
- Twin LED light included
Specifications
| Maximum Cutting Capacity | 0 Degree (Right Angle) | 58 x 310mm |
| Mitre Right / Left 45 Degree | 58 x 218mm | |
| Bevel Left 45 Degree | 39 x 310mm | |
| Bevel Right 45 Degree | 16 x 310mm | |
| Capacity | Mitre Angle: Left | 0 - 45 degree |
| Mitre Angle: Right | 0 - 57 degree | |
| Bevel Angle: Left & Right | 0 - 45 degree | |
| No Load Speed | 4,000 (min-1) | |
| Blade Diameter | 185mm | |
| Weight (Inc Battery) | 15.4kg | |
| Dimensions | W x D x H | 455 x 750 x 430mm |
| Battery Type |
Compatible with HiKOKI MultiVolt batteries |
|
Related Documents
C3607DRA(H4Z) - Product ManualC3607DRA(H4Z) - Parts Diagram
C3607DRA(H4Z) - Product Card
C3607DRA(H4Z) - Hi-Res Image
