Description
- All metal keyless chuck
- AHB (Aluminium Housing Body)
- Safety slip clutch
- Full speed reverse
- Lock off (deadman) variable speed trigger and dial
- Carbon brush rotation system increases power and extends brush life
Specifications
|
Chuck |
13mm keyless |
|
|
Capacity |
Concrete
Steel
Wood |
22mm
13mm
40mm |
|
Input power |
1,120W |
|
|
No load speed |
Low
High |
0 - 1,100 (min-1)
0 - 3,000 (min-1) |
|
Impact rate |
Low
High |
0 - 8,100 (min-1)
0 - 22,000 (min-1) |
|
Weight |
3.0kg |
|
|
Length |
363mm |
|
|
Standard accessories |
Chuck key, side handle, depth gauge and stackable case |
|
Related Documents
DV22V(H6Z) - Product ManualDV22V(H6Z) - Parts Diagram
DV22V(H6Z) - Product Card
DV22V(H6Z) - Hi res image
